Hyundai Ioniq Electric 38 kWh (2016-2022) Tech Specs
Battery Capacity Gross/Useable 41/38.3 kWh
Hyundai Ioniq Electric 38 kWh - Performance Specs
- Power: 100 kW (134 hp)
- Torque: 295 Nm 218 lb-ft
- Number of Engines: 1
- Drive: Front
- Acceleration 0-60 mph: 9.6 s
- Acceleration 0-100 km/h: 9.9 s
- Acceleration 0-62 mph: 9.9 s
- Acceleration 0-160 km/h: 26 s
- Acceleration 0-100 mph: 26 s
- Top Speed: 165 km/h 103 mph
- Quarter Mile (402.3 m): 16.5 s
Hyundai Ioniq Electric 38 kWh - Official Range and Energy Consumption (Combined)
- WLTP Range (TEL*): 311 km 193.2 mi
- WLTP Consumption (TEL*): 13.8 kWh/100 km 22.2 kWh/100 mi
- Petrol/Gasoline equivalent: 1.55 l/100 km 151.8 MPGe
* TEL (Test Energy Low) indicates the lowest values (most economical) with the lightest set of options
TEH (Test Energy High) indicates the highest values (least economical) with the heaviest set of options
Hyundai Ioniq Electric 38 kWh - Battery
- Battery Type: Lithium-ion Polymer
- Battery Capacity Gross: 41 kWh
- Battery Capacity Useable: 38.3 kWh
Hyundai Ioniq Electric 38 kWh - Dimensions and Weights
- Body Type: Liftback
- Length: 4470 mm 175.98 in
- Width: 1820 mm 71.65 in
- Height: 1450 mm 57.09 in
- Wheelbase: 2700 mm 106.3 in
- Weight: 1602 kg 3532 lbs
- Max Payload: 443 kg 977 lbs
- Weight Distr. Front/Rear: 50/50 %
- Trunk / Boot Space: 357 l 12.6 ft3
- Trunk / Boot Space Max: 1417 l 50 ft3
- Frunk Space:doesn't have a frunk
- Ground Clearance: 140 mm 5.51 in
- Min Turning Circle (curb-curb): 10.6 m 34.8 ft
- Tire Standard: 205/60 R16
- Seats max.: 5
Hyundai Ioniq Electric 38 kWh - Charging
- AC On-Board Charger Standard: 7.4 kW
- DC Fast Charging: 50 kW
- DC Charge Port: CCS
- Charge Port Location: Rear Left
Hyundai Ioniq Electric 38 kWh - AC Charging Times (home, work, hotel)
Select State of Charge (SOC):
The maximum on-board charger power of the Hyundai Ioniq Electric 38 kWh is 7.4 kW.
All figures in the table above are assumed approximate values under optimal conditions.
Hyundai Ioniq Electric 38 kWh - DC Fast Charging Times
Select State of Charge (SOC):
The maximum fast charging power of the Hyundai Ioniq Electric 38 kWh is 50 kW.
All figures in the table above are assumed approximate values under optimal conditions.
Hyundai Ioniq Electric 38 kWh - Others
- Dedicated EV Platform: No
- Drag Coefficient Cd: 0.24
Hyundai Ioniq Electric - Safety - Crash Tests
-
Euro NCAP see results 5 stars
-
IIHS see results
Euro NCAP and IIHS: this is the crash test of the ICE or Hybrid version (the electric version has not been tested yet)
Compare the parameters of all the Hyundai Ioniq Electric variants
- Battery type
- Battery - gross
- Battery - usable
- AC charge power
- DC charge power
- Charge port location
- Max range WLTP
- Consumption WLTP
- Acceleration 0-100 km/h
- Acceleration 0-60 mph
- Quarter mile
- Top speed
- Power
- Torque
- Length
- Width
- Height
- Wheelbase
- Weight
- Trunk / Boot Space
- Frunk Space
- Turning circle
- Driven axles
- Drag coefficient Cd
- Ground clearance
The technical information on this page are used from official data provided by the car companies and figures measured by our editorial staff and/or other independent persons. For further details, please visit the manufacturer's website.
If you think any of the information is wrong, please let us know.
